Servo motor regulator for X-drive transfer case type ATC400 ATC500 ATC700

mounted on X3 and X5 from 2003 to 2010

Original BMW part exists under several references for example: 27 10 7 566 296, 27102449709, 27107566250 etc..

Delivered without the calibration resistor

Servo motor regulator for X-drive transfer case type ATC400 ATC500 ATC700

mounted on X3 and X5 from 2003 to 2010

Original BMW part exists under several references for example: 27 10 7 566 296, 27102449709, 27107566250 etc..

BMW Xdrive servo motor repair kit

This repair kit for the X-Drive regulation motor allows you to completely overhaul the reduction part of the servomotor

With the mechanical parts and the seals allowing the watertightness of the servomotor to be reestablished as new

Original BMW parts with carbon fiber reinforced sprocket

Carbon fiber reinforced Xdrive PA servo motor sprocket

Much stronger than the original BMW sprocket

Part guaranteed for 2 years

Important: Remember to drain the X drive transfer case every 60,000 km with BMW DTF1 oil, otherwise serious damage may occur.

Servo motor regulator for X-drive transfer case type ATC300

fitted to Series 3 and some Series 5

Original BMW part

BMW price €709.76 excluding VAT

Pre-assembled friction disc assembly for Xdrive ATC400 transfer case

mounted on X3 from 2003 to 2010

Pressure plate for X-drive transfer case type ATC400 and ATC300

mounted on:

• ATC-300 - BMW 5 series xi/xd E60
• ATC-300 - BMW 3 series xi/xd E90
• ATC-400 - BMW X3 E83 2003 -> 2006
• ATC-400 - BMW X3 E83 LCI 2007 -> 2010

Disc pressure arm for X-drive transfer case type ATC400 and ATC300

mounted on:

• ATC-400 - BMW X3 E83 2003 -> 2006
• ATC-400 - BMW X3 E83 LCI 2006 -> 2010
• ATC-500 - BMW X5 E53 LCI 2003 -> 2006
• ATC-700 - BMW X5 E70 2006 -> 2009
• ATC-700 - BMW X5M E70 2006 -> 2013
• ATC-700 - BMW X6 E71 2007 -> 2010
• ATC-700 - BMW X6M E71 2007 -> 2013

Repair kit for X-drive type ATC500 transfer case

mounted on ATC-500 - BMW X5 E53 LCI 2003 - 2006

Kit to be used if the original transfer case servomotor is in good condition and therefore reusable

Repair kit for X-drive type ATC500 transfer case

mounted on ATC-500 - BMW X5 E53 LCI 2003 - 2006

Kit including original BMW servomotor

Clutch bell friction discs for transfer case Xdrive ATC300 - 400 - 500 - 700

Servo motor regulator for X-drive transfer case type ATC350-ATC35L-ATC450-ATC45L

mounted on X1 X5 X6

ATC350 - BMW X1 - 2009 - 2015
ATC35L - BMW X1 - 2010 - 2015
ATC450 - BMW X5, X6 - 2010 - 2012
ATC45L - BMW X5, X6 - 2012 - 2014

Original BMW part

Parts supplied only for assembly by a professional with mandatory programming by an approved BMW workshop.
